What's New in Revit Architecture 2010 Recording

If you missed my recent webcast of What's New in Revit Architecture 2010, here is a link to the recording of my webcast. The recording is a little over an hour long.

http://209.16.228.54/webcast/WhatsNewInRevitArchitecture2010.swf

Enjoy!

Space Enhancements in Revit MEP 2010

Revit MEP 2010 has many new features. Here are just a couple when working with Spaces.

Spaces have been enhanced in two major areas. First the ability to create spaces has been improved with the addition of the Place Space Automatically tool. This will allow users to place all the spaces for the entire model with a single click. This is a huge time saver for creating spaces.

The new Place Space Automatically tool.

The second enhancement to spaces is found in the properties. The properties have been improved to give us the ability to further define the space type. The space type has been expanded to include Energy analysis settings. These include the ability to specify an Occupancy Schedule, Lighting Schedule, and Power Schedule. These schedules will dictate usage percentage factors. If the proposed building will be primarily used between the hours of 8:00-5:00, these can be specified and taken into account in analysis.

A custom Occupancy Schedule for a Space type with the hours set for the warehouse hours.

I will try to blog about more new features in Revit MEP 2010 soon.

Cool New Stuff in Revit Architecture 2010

It's that time of year again! Time to gear up for the new release of the Autdesk products. Revit Architecture 2010 has some nice new features. Here are some of my favorites that have not gotten much publicity. Enjoy!

1. Export Building Site Tool - This is a great addition to allow you to export your building site and model to your Civil engineer. It grabs the site, model, building footprint, property lines, and UTILITY Connections and groups them into a new .adsk file format. I especially love the ability to show the Civil engineer where the utility connections are located. Not only that, if they are using Civil 3D 2010, they can actually connect their pipes to our connections.



2. The Press & Drag check box on the bottom right corner of the screen. I have always hated how easy it was to accidentally pick and move something inside of Revit without meaning to. Now you can uncheck this check box and you have to first pick the item you want to move before you can move it. This will make my life so much easier!


3. The ability to include sheet revisions in a Drawing List. We are no longer limited to just showing revisions on the titleblocks. We now have the ability to add the Current Revision and Current Revision Description to a Drawing List.


4. The ability to label slopes. This was high on my wish list. I now can call out the slopes on my roofs and floors.


Those are my top 4 non-publicized new features inside of Revit Architecture 2010. More to come soon!

Seeing Things Above

Revit has some great tools to help us view a model from many different positions. We can have plans, ceiling plans, elevations, sections, 3d views or 3d sections. This enables us to view what we want when we want to see it.

I get lots of questions concerning the View Range in the View Properties. The View Range will allow you to change your Cut Plane and set your upper and lower limits. This is very helpful, but you need to understand one key rule: Revit will not actually show an item unless the view is cutting through that item.

A floor plan is typically a plan that is looking down and is cut by default 4'-6" above the level line. This means that a light fixture that is 8'-0" above the level line is not being cut by the cut line, which means that the light fixture will not be seen in the floor plan. One of the most common questions I get is "how do I get Revit to show the something on the ceiling on a floor plan?"

Here is a quick fix to be able to show light fixtures in your floor plan. Simply open the light fixture in the Family Editor, and draw a WHITE Model line from the fixture to the level line. This will cause the cutline to cut through the white model line and then show up on the floor plan. It should be white so it will not show up on the screen or on a plot.

To create the Model line, it works best to draw it in an elevation view. Once it is drawn you will need to create a new subcatagory in the Object Styles under Light Fixtures and assign that catagory to use a white line.

Then you will need to change the line to be assigned to the new sub catagory.

Load the light fixture back into your project and your light fixture now shows up in the floor plan. You may also want to override the graphics of the linework for the light fixture in the floor plan to be a hidden or dashed line.

This is a quick and easy way to show items above that are not being cut by the cut plane.

Using Schedule Keys in Revit

I have found that one of the most unknown parts of Revit is creating schedule keys. I think creating schedule keys are a great way to promote standards, and provide the information you need on your schedules.

Schedule Keys are nothing more than a schedule of keys that you can use in other schedules. They are associated to a particular catagory and create a paramater for that catagory that can be used in schedules. There are many instances where these could be beneficial. I will give one example to show you how you can begin to use them in your projects.

Let's say you want to create a typical room finish schedule, but it is early on and you are not sure what the actual finishes will be. You do know what the finish material will be but not the actual color or manufacturer. For example, you want to call out CPT-1, or TILE-1 to call out the material as carpet or tile, but you do not know the particular carpet or tile. I am able to create a schedule key for the types of materials and apply them to my room finish schedule, and fill what the actual keys refer to when that information is known.

Let's begin by creating the schedule key.

I begin by starting a new Schedule by clicking on Schedule/Quanity from the View tab on the Design Bar. I select Rooms as my catagory since I am creating a key for the room finish. I then select to create a Schedule Key as opposed to a Building Component type of schedule. I also fill in the Key Name as Floor Finish. This is the name of the new parameter that will be added to rooms. I select OK to go to the next step.

In the Schedule Properties - Fields Tab, the Key Name is added automatically to the Scheduled Fields column. I need to add one additional field for the manufacturer of the finish. I do this by clicking on Add Parameter and fill in the name Floor Manufacturer.

The Key Name and the Floor Manufacturer are the only fields that are needed for the schedule key. Select OK to close the dialog box and to open the schedule key view.

In the schedule key view, you can add new Key Names by clicking the NEW icon on the Options Bar. Create the common finishes that you typically use. Others can be added later, and the manufacturer information can be added at a latter time.

Now when you either go to a Room properties or create a Room Finish Schedule, the Floor Finish key parameter will be listed. You can select what type of floor finish by using the drop down arrow to list the keys that were created in the Schedule Key.

The schedule key can be created in your standard Revit template file and the information can be filled in as it is known. This will create a standard list of finish names to be used in your office.

Schedule Keys are the key to creating consistancy and standards in Revit.

AU Customer Appreciation Mixer

Autodesk University is almost here! I am gearing up for a jam packed week of classes and events. My schedule is crazy this year. I am not sure when I will have a chance to rest, but it will be worth it (I think.)

I will be teaching 3 classes, and assisting as a lab assistant for 2 labs plus attending sessions on Revit and Construction.

Looking at the schedule, it appears that my nights will be just as busy... and I am not the party animal if you do not know me very well.

If you are an Alacad customer, I want to personally invite you to attend a special Customer Appreciation Mixer. Alacad wants to say Thank You for being our customer by hosting a mixer on Monday night at the V Bar from 7:00-8:00. Shoot me an email to ensure that you have your ticket to join us. You must have a ticket to attend.

I am looking forward to meeting many of you that are attending. Find me if you can in the sea of 10,000 attendees. See ya in Vegas!

Enhancing Elevations in Revit

Creating elevations in Revit are as simple as placing a callout. Enhancing the elevations once they are created is another task. Tools like the Linework, Split Face, and Paint help us enhance the elevations. The Linework tool will allow us to change the lineweight of any line in the view, or set it to be invisible if we do not want to see it.

The Split Face and the Paint tools allow us to split the surface of a wall and apply a different material to that portion of the wall.


These tools are great, but there is nothing built in the program to vary the lineweight automatically based on the depth of view. It would be nice for Revit to allow us to set some depth distances to automatically switch lines that are in the forground to be thick and the lines in the distance to be thin. Maybe some day we will have that.

Another tool that I find handy that few people know about is the Silhouette Edge setting. This setting will allow you to beef up the lineweight of the silhouette edge. This setting is found in the Advance Model Graphics Settings dialog box.

Inside the Advance Model Graphics Settings dialog box you can set the silhouette edges to any linetype you have in your project. This will automatically apply this linetype to the outside edges of your view.

Here is a before and after view with the Silhouette Edges changed to Medium Lines.

Silhouette Edge set to None

Silhouette Edges set to Medium

This should give you a head start on enhancing your elevations. You can still use the Linework tool with the Silhouette Edges turned on.

CADD Camp and AU

For those that are in the Alabama area, do not miss out on this year's CADD Camp in Birmingham on September 30!

We will be hosting a full day of training on Revit. I will also be presenting the basics of NavisWorks during lunch.

Check out the course offerings and sign up at:

http://www.augievents.com/Birmingham/tabid/432/language/en-US/Default.aspx.

This will be like a mini-one-day Autodesk University.

If you are fortunate enough to attend this year's Autodesk Unversity, check out the three classes that I will be presenting.

• AB110-6 AutoCAD® Architecture: Making Spaces Work For You!
• CV310-4 From Dirt to Doors: Making AutoCAD® Civil 3D® and Revit® Architecture Work Together In Harmony
• AB404-3 From the Existing to the Beyond with Revit® Design Options and Phases

These are both great opportunities, don't miss out!

Seek for Content

There is a new Autodesk website available to search for Revit Content.





Go to http://seek.autodesk.com/. You can search by keyword, browse by CSI format, and filter it down by manufacturer. It appears to pull from multiple websites. It is a one stop shop for all your content searches.

There is also a built in search line inside of the Revit 2009 products that will launch this site.

AutoCAD Architecture 2009

AutoCAD Architecture 2009 has some cool new features. I believe users will be excited to see the new enhancements. Here are a few of my favorites.

Wall Endcaps

Now AutoCAD Architecture 2009 makes it easier to create custom wall endcaps. While previous releases had this ability, enhancements to key “grip-edit” functionality makes the process more intuitive and streamlined.

Additionally, it’s easier than ever to modify endcaps using the “Auto-Calculate” feature and the integration of AEC Modify Tools.

Because of this, it’s now possible to extend, trim, and even merge wall components with AutoCAD linework, allowing you to create the endcap condition that you want… in fewer steps!

Match Properties Update

If you’re an AutoCAD user, you are probably aware of the Match Properties feature, commonly referred to as the “Paintbrush tool.”

Now, in AutoCAD Architecture, the “Paintbrush Tool” has been extended beyond AutoCAD entities to also work with AEC objects, such as walls, doors, and windows. The object matching paintbrush will allow users to match the style and graphic properties of one object to like objects in a drawing.

With this update, you’ll be able to quickly make design revisions to linework and objects, so that you don’t have to learn a separate set of revision commands!

Multiline Tags

Another feature around construction documentation is the ability to annotate with multi-line tags.

Now you can have more control over the way text appears in your construction documents by specifying text wrapping, rotation, and alignment in its tags with intuitive grips. With these tools, you’ll find it easier to communicate your design intent clearly.

These are just a few of the improvements. I believe the users will be happy with this release.
